Pool Robotic Cleaner Tether 2 Core Power Wires ROV Floating Cable
Product Specifications
| Attribute |
Value |
| Model NO. |
LK-427 |
| Current |
300V |
| Insulation Material |
PE |
| Sheath Material |
PUR Foam |
| Material Shape |
Round Wire |
| Wire Core Material |
Tinned Wire |
| Brand |
Linke |
| Name |
Floating Cable |
| Copper |
Tinned Copper |
| Core |
Multiple |
| Jacket |
PUR Foam |
| Transport Package |
Roll |
| Specification |
50*50*40CM |
| Trademark |
LINKE |
| Origin |
China |
Key Features
- UL Certified floating power cable for underwater applications
- Special flexible sheath material with bending life exceeding 6 million cycles
- Excellent flexibility, wear resistance, and waterproof properties
- Designed specific gravity allows cable to float on water surface
- Resistant to oil, acid, alkali, and features anti-aging properties
- Available in various configurations with thermoplastic or thermoset insulation
Product Variants
| Product Code |
Commodity Name |
Specification Scope |
Shield Layer |
Components |
Sheath Material |
| PFC9980-P |
Underwater power supply buoyancy cable |
0.75-16.0mm² (2-5 cores) |
AL+Braid |
Kevlar braid and filling |
PUR foam |
| PFC9980-K |
Underwater control buoyancy cable |
0.35-2.5mm² (2-61 cores) |
AL+Braid |
Kevlar braid and filling |
PUR foam |
| PFC9980-TX |
Underwater communication buoyancy cable |
Ф0.51mm (2P,4P,8P) |
Individual screen+BraidTC+Overall Screen |
Kevlar braid and filling |
PUR foam |
| PFC9980-ROV |
Underwater Video Surveillance Buoyancy Cable |
0.22-0.35mm² (2P,4P,8P) |
|
Kevlar filing |
PUR foam |
Zero Buoyancy Cable Structure
- Conductor: Tin plated multi strand ultra-fine oxygen free copper wire
- Insulation: Special nitrile PVC blend/special TPE/PE material/PTFE (customer selectable)
- Filling: Optional polyester yarn/bulletproof silk fiber
- Shielding: Multiple options including tin plated copper wire textile shielding (density ≥85%)
- Sheath: Optional polyurethane (PUR) foam/TPE foam/PE foam
- Rated Voltage: 300/300V
- Test Voltage: 2500V
About Linke Cable
Linke Cable Technology Co., Ltd is a leading Chinese cable manufacturer specializing in R&D, production and marketing of high-quality cables for over 10 years. We provide custom cable solutions worldwide, with expertise in various specialized cables including underwater buoyancy cables.
Certifications
- UL1007, UL1185, UL1672, UL10070
- UL10483, UL1015, UL1569, UL10012
- UL10269 (Single conductor, thermoplastic insulation)
- UL2095, UL2129, UL2468, UL2586
- UL2725, UL20233, UL20280, UL20963
- UL2103, UL2463, UL2517, UL2587
- UL2835, UL20276, UL20549, UL21198
- ISO9001, ISO13485, TS16949
- CNR-Appliance Wiring Material certified
Frequently Asked Questions
1. Are you a manufacturer or trading company?
We are a professional manufacturer. We can control your order from the first beginning to the last. Welcome to visit us. We'll pick you up in Shenzhen.
2. How can I get a sample to test your quality?
The samples are free for you. New clients are expected to pay for the courier cost.
3. What's your Minimum Order Quantity?
Normally 100m. However, the cable is very heavy. You'd better order a suitable quantity to avoid the high freight. Sea transportation is the best option.
4. Can I get a discount?
It depends on your quantity. We can make a discount and afford the freight. Please kindly contact us.
5. Does your company accept OEM production?
Yes, we can print your company name, and even customize the quality card to promote your company.
